Type of light: infrared light
Housing: threaded type
Function principle: Through-beam sensor
Operating voltage [V]: 10...36 DC
Current consumption [mA]: < 30
Protection class: II
Reverse polarity protection: yes
Wave length [nm]: 880
Electrical design: PNP
Output function: light-on/dark-on mode; (programmable)
Max. voltage drop switching output DC [V]: 2.5
Function check output: yes
Max. voltage drop of function check output [V]: 3.5
Max. current load for function check output [mA]: 10
Permanent current rating of switching output DC [mA]: 200
Switching frequency DC [Hz]: 320
Short-circuit protection: yes
Type of short-circuit protection: pulsed
Overload protection: yes
Transmitter / receiver: receiver
Range [m]: < 4
Range adjustable: yes
Ambient temperature [°C]: -25...60
Protection: IP 65
Weight [g]: 40.7
Dimensions [mm]: M12 x 1 / L = 74
Materials: housing: brass white bronze coated
Lens material: PMMA
Display: switching status: 1 x LED, yellow operation: 1 x LED, green function: 1 x LED, red
