Light type: Red light
Operating voltage [V]: 10...30 DC
Current consumption [mA]: 22; ((24 V))
Protection class: II
Reverse polarity protection: Yes
Wave length [nm]: 633
Electrical design: PNP
Output function: Light/Dark mode; (programmable)
Max. voltage drop switching output DC [V]: 2.5
Permanent current rating of switching output DC [mA]: 200
Switching frequency DC [Hz]: 1000
Fixed current rating of switching output DC [mA]: 100
Short-circuit protection: Yes
Short-circuit protection type: Pulsed
Sensing range [mm]: 2...200; (white paper 200 x 200 mm)
Sensing range on white object (90% remission) [mm]: 2...200
Sensing range on gray object (18% remission) [mm]: 4...200
Sensing range on black object (6% remission) [mm]: 8...200
Range adjustment: Yes
Maximum light spot diameter [mm]: 8
Reference light spot size: Range
Background suppression available: Yes
Ambient temperature [°C]: -25...80
Degree of protection: IP65; IP67; IP68; IP69K
Weight [g]: 51.4
Dimensions [mm]: 56 x 18.2 x 46.8
Lens alignment: Lateral lens
Tightening torque [Nm]: 1; (screw)
Switching status display: 1 x LED, yellow
Operating status display: 1 x LED, green
Connection: Cable: 0.3 m, PVC; 3 x 0.25 mm | Connector: 1 x M12; Coding: A
