Light type: red light, blue light, green light
Operating voltage [V]: 10...36 DC
Current consumption [mA]: 50; (24 V)
Protection class: II
Reverse polarity protection: Yes
Wave length [nm]: 625; 525; 465
Electrical design: PNP/NPN; (automatic detection of PNP/NPN load)
Output function: light/dark mode; (programmable)
Max. voltage drop switching output DC [V]: 2.5
Permanent current rating of switching output DC [mA]: 200
Switching frequency DC [Hz]: 10000
Note on switching frequency [Hz]: for step tolerance 5
Short-circuit protection: Yes
Type of short-circuit protection: Pulse
Overload protection: Yes
Detection range [mm]: 18...22
Max. light spot width [mm]: 1.5
Max. light spot height [mm]: 5
Response time [s]: < 0.05
Ambient temperature [°C]: -25...60
Protection: IP67
Weight: 79.5 g
Dimensions [mm]: 56 x 18.2 x 46.8
Lens alignment: side lens
Switching status display: 1 x LED, yellow
Teach-in function: Yes
Electrical lock: Yes
Connection: Connector: 1 x M12; coding: A
