Specifications
Rated power (KVA/KW): 5/4.5
Noise level (dBA): 60
Input specification
Nominal voltage (VAC): 220
Voltage range (VAC): 120-276
Frequency range (Hz): 40-70
Number of phases: 1
Output specification
Voltage (VAC): 208 / 220 / 230/ 240 (±1%VAC)
Frequency (Hz): Battery mode (50/60 ± 0,1%Hz)
Switching time (second): 0 second
Waveform: Standard sine wave
Connection port
Communication port: RS-232
Battery
Quantity and type: 16 x 12V x 7Ah; Optional external battery (HD-5RS)
Power backup time (100% load): 5-7 minutes
Charging time: reaches 90% within 8 hours of charging
Dimension & Weight
Product dimensions (mm): 440 x 660 x 176 (L x W x H)
Weight: 58kg
Operating environment
Operating temperature: 0ºC – 40ºC
Humidity: 20 – 90% without condensation
