Timing measurement:
- 12 contacts Inherent open (close) time
- Open (close) in phase synchronization
- Open(close) phase-to-phase synchronization
- Close (open) bounce time (number of bounce)
- Test range: 0.01ms to 18000ms, resolution: 0.01ms
Double-end grounded switch measurement:
- 3(6) contacts Inherent open (close) time
- Open (close) in phase synchronization
- Close (open) bounce time and waveform
Velocity measurement:
- Just open (just close) velocity
- Specified time period (travel or angle) average velocity
Velocity measurement range:
- 1mm sensor: 0.01~25.00m/s
- 0.1mm sensor: 0.001 to 2.50m/s
- 0.5°angle sensor: 1 wave cycle / 0.5°
Travel measurement:
- Moving contact travel (travel)
- Contact travel (open distance)
- Travel overshoot and return (over-travel)
- Sensor: 50mm, Resolution: 0.1mm
- 360 line sensor: 360º, resolution: 0.5º
- Optional sensor: 300mm, 1000mm, acceleration sensor
Current display: Maximum current 30A, resolution: 0.01A
Instrument power supply: AC/DC 220V±10%; 50Hz±2%
DC power output: DC power output: DC20~260V continuously adjustable, DC110V≤30A (short-term), DC220V≤20A (short-term)
External trigger voltage: AC/DC10-300V, current≤120A
Isolated switch measurement range:
- Voltage output: DC10~260V (adjustable);
- Power output time: 0.01-20 seconds (can be set);
- The maximum acquisition time of the fracture signal is 200 seconds;
- Measurable fracture open, close time, three phases different period, bounce time and time
- Measurable fracture open, close time, three phases different period, bounce time and time
Host volume: 360*260*170mm
Operating Environment: -20ºC~+50ºC
