IEC 61850 communication port
Function: Any configuration of IEC 61850 9-1/9-2 SMV transmission, receiving or GOOSE transmission and reception
Interface type: LC optical port
Quantity: 8 pairs, 6 pairs*100M adaptive, 2 pairs *100/1000M adaptive
Wave length: 1310nm
IEC 60044 communication port
Function: GB/T 20840.8 , DL/T 282, Q/GDW441 message received and send
Interface type: ST
Quantity: 6*sending interface , 2* receiving interface
Phase
Range: 0~360°
Accuracy: ±0.1°
Resolution: 0.1°
Frequency
Range: 0~1000Hz
Accuracy: <±0.001Hz(0~65Hz)
<±0.01Hz(65~450Hz)
<±0.02Hz(450~1000Hz)
Resolution: 0.001Hz
Time
Range: 10ms ~9999.999s
Resolution: 1ms
Binary contact input
Quantity: 8 pairs, Can be connected to idle contact and with potential contact (0~250V)
Binary contact output
Quantity: 6 pairs, 2 pairs are fast output
Breaking capacity: DC250V /0.5A
Response time: <100us
Synchronize
Interface type: GPS/BD ANT; IRIG-B/PPS optical signal; IRIG-B/PPS electric signal; IEEE 1588
Quantity:
1*GPS/BD ANT;
2*IRIG-B/PPS optical signal : 1* time synchronization, 1* time giving;
2 pairs*IRIG-B/PPS electric signal :1 pair *time synchronization, 1 pair * time giving;
1 pair* IEEE 1588
Wireless connection
Interface type: WIFI
Wired connection
Interface type: 100M Lan port , RJ45
Quantity: 2 pieces
Analog small signal input
Interface type: Aviation plug, AC voltage
Quantity: 12 channel
Analog small signal output
Interface type: Aviation plug, AC voltage
Quantity: 12 channels
Power supply
Voltage: AC/DC 220V , Allowable deviation: -20%~15%
Frequency: 47~65Hz
USB interface
Quantity: 2 pieces
Working environment
Working temperature: -10℃~50℃
Humidity: ≤95%, non-condensation
Others
Weight: 5.5 kg
Dimension: 146*390*212mm(L*W*H)
Online interface: RJ45
Display: 10.4 inch true color LCD touch screen
