Measuring principle 90° diffusion ray measuring method (ISO7027 Method)
Measuring range 0~5NTU, 0~100NTU, 0~4000NTU
Source of light LED(860±30nm)
Reproducibility Below <±1% F.S
Precision Below <±1% F.S
Minimum scale unit 0.0001NTU
Measurement unit NTU, FTU, FNU, mg/L
Applicable temperature 0~50℃
Correction method Two-point calibiation, zero memory function
Cleaning method Wiper cleaning method, time-setting of cleaning cycle
Screen display Digital LCD
Output signal Sensor : RS-485, monitor : 4~20mA, 0~5V, RS-485, LAN communication(option)
Alarm setting Two points (high, low), LCD display & buzzer setting
Power AC 220V, 60Hz, AC 110V(option)
Probe material Exterior : SUS316L, interior: PVC
Weight 5kg
Sample insertion &
outflow fitting 8mm / 12mm
Cable water-proof IP68 (max. 2m underwater)
Data storage function Max. 64,000
Self-diagnosis function Lamp, Detector
Cable length Standard : 5m( option: orderable)
Measuring chamber Speed of flow-in: 300~400ml/min recommended
