Gain: 2.5 dBi, 3.5 dBi, 4.5 dBi, 5 dBi, 6 dBi, 6.5 dBi, 6.5 dBi, 5.5 dBi
VSWR: 1.8, 1.9, 2, 1.6, 1.6, 1.5, 1.5, 2
Style: Round
Height: 6.8 mm
Length: 87 mm
Impedance: 50 Ohms
Cable Type: 0.35 M SucoForm 141 C U CMP
Application: Building Coverage
Unit Weight: 818 g
REACH - SVHC: Details
Mounting Style: Wall Mount
Number of Bands: 8 Band
Center Frequency: 658 MHz, 744 MHz, 875 MHz, 1937 MHz, 2290 MHz, 2450 MHz, 2595 MHz, 3750 MHz
Mechanical Style: Module
Maximum Frequency: 4.2 GHz
Minimum Frequency: 617 MHz
Termination Style: Connector
Antenna Connector Type: 4.3-10 Female
Protocol - WiFi - 802.11: WiFi, WLAN
Maximum Operating Temperature: + 55 C
Minimum Operating Temperature: 0 C
Protocol - Cellular, NBIoT, LTE: Cellular (NBIoT, LTE), AMPS, GSM, CDMA, UMTS
