Specifications:
- Display: 4 digits, 10 mm LCD, with blue backlight
- Parameters: Ra, Rz
- Measuring Range
+ Ra: 0.050-10.00um/1.000-400.0uinch
+ Rz: 0.020-100.0um/0.780-4000uinch
- Accuracy: ≤±10%
- Fluctuation of display value: Not more than 6%
- Sensor :
+ Test Principle: Highly sophisticated inductance type
+ Radius of Probe Pin: 5um
+ Material of Probe Pin: Diamond
+ Dynamo-measurement of Probe: 4mN(0.4gf)
+ Probe Angle: 90°
+ Vertical Radius of Guiding Head: 48mm
- Maximum driving stroke: 17.5mm/0.7inch
- Cutoff length (l): 0.25mm / 0.8mm / 2.5mm optional
- Evaluation length: 5l
- Driving speed:
+ sampling length = 0.25mm Vt=0.135mm/s
+ sampling length = 0.8mm Vt=0.5mm/s
+ sampling length = 2.5mm Vt=1mm/s
+ returning Vt=1mm/s
- Profile digital filter
+ Filtered Profile: RC
+ Filtered Profile: PC-RC
+ Filtered Profile: Gauss
+ Non-Filtered Profile: D-P
- Resolution :0.001μm if reading <10μm
+ 0.01μm if 10μm≤reading<100μm
+ 0.1μm if reading ≥100μm
- Evaluation length : 5 cut-off
- Power Li-ion battery: rechargeable
- Operating conditions: Temp. 0~40°C
+ Humidity <80%
Standard Accessories:
- Carrying case.................1pcs
- Main unit......................1pcs
- Standard Sensor.............1pcs
- Standard Sample Plate...1pcs
- Power Adapter..............1pcs
- Operation Manual.........1pcs
- Screwdriver..................1pcs
- Adjustable Leg..............1pcs
- Sensor Protector...........1pcs
Optional Accessories:
1. Cable and Software for RS-232/USB
2. Extension Rod
3. Groove stylus
4. Curvature Probe
5. Measurement Stand
6. Bluetooth interface
