Specifications:
- Preload:98.1N (10kgf)
- Total test force:588.4N (60kgf), 980.7N (100kgf), 1471N (150kgf)
- Scales:HRA, HRB, HRC, HRD, HRE, HRF, HRG, HRH, HRK, HRL, HRM, HRP, HRR, HRS, HRV
- Load dwell duration: 2～50s, can be set and stored
- Resolution :0.1HR
- Display:High definition backlight LCD
- Operation:Menu selectable, Membrane keypad
- Upper/lower limits setting & alarming
- Data statistics: Avg., Max., Min., S, R available
- Curved surface correcting automatically
- Memory: Max 500 items of test results stored automatically
- Data output: RS-232 to micro printer, USB port to external PC
- Testing space:260mm in vertical, 150mm in horizontal
- Dimensions: 710mm×210mm×830mm
- Power supply: AC, 220V/110V, 50～60Hz, 4A
- Net weight: 100kg
Standard configuration:
- Host machine: 1
- Standard hardness block for A scale: 1 pc
- Standard hardness block for B scale : 1 pc
- Standard hardness block for C scale: 1 pc
- ball indenter (1/16″): 1 pc
- 120°cone diamond indenter: 1 pc
- Mounting screws for indenter: 2 pcs
- Flat anvil: 1 pc
- “V ”shape anvil: 1 pc
- Power supply wire: 1 pc
- Screwdriver for indenter mounting: 1 pc
- Dust cover: 1 pc
Optional accessories:
- Short diamond indenter
- Chisel diamond indenter
- Slender diamond indenter
- 1/8″ball indenter and spare steel ball
- 1/4″ball indenter and spare steel ball
- 1/2″ball indenter and spare steel ball
- φ225 anvil
- φ150 anvil
- Standard hardness block for other scales
- Micro printer
