Test force: 5～187.5kgf
Brinell scale: HBW1/5,HBW2.5/62.5,HBW1/10,HBW2.5/15.625,HBW1/30,HBW2.5/31.25,HBW2.5/62.5,HBW10/100,HBW5/125,HBW2.5/187.5 (select 10 scales)
Hardness resolution: 0.1HBW
Rockwell scale: HRA,HRB,HRC,HRD,HRE,HRF,HRG,HRH,HRK,HRL,HRM,HRP,HRR,HRS,HRV
Hardness resolution: 0.1HR
Vickers scale: HV5,HV10,HV20,HV30,HV40,HV50,HV60,HV80,HV100,HV120 (select 10 scales)
Hardness resolution: 0.1HV
Objective: 2.5X,5X(10X,20X optional)
Magnification of microscope: Brinell:37.5X, Vickers:75X
Hardness measurement: Brinell:8～650HBW Rockwell:20～100HR Vickers:8～2900HV
Data output: LCD display,U disk
Max height of specimen: Rockwell:220mm, Brinell Vickers:150mm
Head - wall distance: 200mm
Dimension: 560*260*800mm
Weight: About 70Kg
Power: AC220V+5%,50-60Hz
Standard Accessories:
- Lighting (internal lighting, external lighting): 1
- Test block(HRC high,HRC low HRB ,HBW2.5/187.5,HV30): 5
- Rockwell,Vickers diamond indenter: Each 1
- Ball indenter(φ1.5875,2.5,5mm): 3
- Eyepiece(15X): 1
- Objective(2.5X,5X): 2
- Sliding test table: 1
- Large, medium, V-test sets: Each 1
- U memory disk, touch pen: Each 1
- Fuse 2A: 2
- Level: 1
- Regulating screw: 4
- Power cable: 1
- Dust bag: 1
- Certificate, warranty card: 1
- Manual: 1
