Input voltage/Current:
50V/6A
500V/60A
Input power: 1200W
Min. operation voltage: 4V@60A
Min rise time@ FS current: 25us
CV mode
Range/Resolution:
50V/0.7mV
500V/7mV
Accuracy: ±(0.03%+0.02%FS)
CC mode
Range/Resolution:
6A/0.09mA
60A/0.9mA
Accuracy: ±(0.03%+0.02%FS)
CR mode
Range: 0.06Ω~83kΩ
Resolution: 16Bits
Accuracy: ±0.1%
CP mode
Range: 1200W
Resolution: 16Bits
Accuracy: ±（0.1%+0.1%FS）
Dynamic mode
Ta＆Tb: 10us~50s
Min.resolution: 10us
Min. rise time: 3A/us
Read-back voltage
Range/Resolution:
50V/0.3mV
500V/3mV
Accuracy: ±(0.015%+0.01%FS)
Read-back current
Range/Resolution:
6A/0.04mV
60A/0.4mA
Accuracy: ±(0.03%+0.02%FS)
Read-back ripple
Range(U/I): 500V/60A
Bandwidth: 10Hz~250kHz
Accuracy: ±0.1%
Protection range
Over-power protection: 1260W
Over-current protection: 63A
Over-voltage protection: 525V
Over-temperature protection: ≒85℃
Specification
Dimension (L*W*D): 483mm*428mm*106mm
Gross Weight: 19.5Kg
