-Display: 4.3 inch TFT-LCD display
-Measurement parameters: ACR,DCV
-Resistance:
+Accuracy: 0.3%
+Range: 0.1μΩ ～ 3kΩ
-Voltage:
+Accuracy: 0.01%
+Range: 10μV～60V
-Signal Source: Measurement current frequency:1kHz; Open circuit voltage:<5V;Test current:<100mA
-Range:
+7 different ranges-3mΩ,30mΩ,300mΩ,3Ω,30Ω,300Ω,3KΩ;
+Auto and manual modes are available in each range
-Measuring speed: 70 meas/sec., 15 meas/sec., 3 meas/sec.
-Maximum display value:
+Resistance: 32,000;
+Voltage: 600,000
-Calibration: Short-circuit reset for all ranges;
-Comparator: 30 sets of data records, 7 bins sorting, bin count
-Others: data/report save, USB disk export,
-Trigger mode: Internal/manual/external trigger
-Interface: RS-232C, Handle (PLC interface), USB(Host)
-Power supply:
+Voltage: 90VAC～250VAC;
+ Frequency: 47Hz～400Hz;
-Power(max): 15VA
-Dimension(L*W*D): 385 mm*249 mm*102 mm
-Weight: 3 kg
