Characteristic impedance: 50 ohm
Frequency range: DC - 50GHz
DC voltage: 100V
DC current: 1A
RF Power @ 10GHz max: 5W
Contact resistance on Au: 0.05 ohm
Insertion loss to 50GHz: -1.5dB
Insertion loss to 50GHz: -13dB
Probe Material (for RF / RF GND): Nickel Alloy or W, BeCu
Probe Material (for DC / DC GND): Tungsten(W) or BeCu
Body Material: Aluminum Alloy
XY position error: Max 10um
Planarity error: Max 10um
Available Pitch: Min 50um / Max TBD
RF Connector: 1.85mm (J)
Connector: 2.54mm Pin header/or Coax+BNC or SMA
