Pitch: 0.4 mm (0.016 in)
Application: Board to Board
Unit Weight: 200 mg
Stack Height: 3 mm
Current Rating: 300 mA
Mounting Angle: Vertical
Number of Rows: 2 Row
Voltage Rating: 30 V
Contact Plating: Gold
Contact Material: Phosphor Bronze
Housing Material: Liquid Crystal Polymer (LCP)
Termination Style: Solder
Flammability Rating: UL 94 V-0
Number of Positions: 48 Position
Insulation Resistance: 50 MOhms
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 35 C
