Mainframe:
Microprocessor controlled LCD module: 8 * 40 characters
Parallel printer interface for on-line documentation: 25-way 'D' connector
Optical-interface for remote control of the generator: built-in
External trigger input/output: Switch / 10 V
Connector for external safety interlock loop: 24 V=
External red and green warning lamps acc. to VDE 0104: 230 V, 60W
Mains power: 230 V, 50/60 Hz
Dimensions (desk top case W * H * D): 471 * 156 * 520 mm³
Weight: 25 kg
Generator Section:
Peak open circuit voltage: 250V (-10 %) to 2.5 kV (+10%)
Oscillation frequencies: 100 kHz ± 10 % | 1 MHz ± 10 %
Repetition rate: 40 Hz | 400 Hz
Magnetic field strength of the first half wave, adjustable: 10 A/m to 100 A/m
Magnetic field decay: 50% of the peak value between the third and sixth period
Polarity of the first half-period: positive and negative
Burst duration: not less than 2 s
HV-output, for connection of the Helmholtz coil: coaxial
Monitor output for current measuring: coaxial
Output current monitor: built-in
Helmholtz Coil HI 100:
Description: Air coil designed for generation of pulsed magnetic fields
Dimensions: 1000 * 1000 mm³
Coil inductance (L): ≈ 5 µH
Coil factor (H/I): ≈ 1.5 /m
