Dimensions L*W*H (mm): 1775 x 940 x 2130
Weight (kg): 750
Rated Load Capacity (kg): 1400
Load Center (mm): 600
Lifting Height (mm): 3000
Mast Height, Extended (mm): 3435
Fork Dimensions twl (mm): 60 x 180 x 1150
Fork Spread (mm): 600/Customizable
Pallet Size (mm): 1200 x 1000
Navigation: Laser SLAM
Display (in): 11
Laser Obstacle Avoidance: Available
Automatic Data Logging: Optional
Bumper Strip: Available
Pallet Position Detection: Available
Fork Infrared Sensor: Available
Emergency Stop Button (SCRAM): Available
Warning Light: Available
Audible and Visual Alarm: Available
Rated Speed (mm/s): 1200
Positioning Accuracy (mm): ±10
Angular Accuracy (°): ±1
Movement Modes: Steering wheel drive, forward, backward, rotation, arcing
Minimum Aisle Width (for 1200*1000 mm pallet) (mm): 2200
Operating Time (h): 6 - 8
Charging Time (h): ≤3 (after full discharge)
Pallet Recognition: Optional
Code Reader: Optional
Adjustable Forks: -
RFID Reader: Optional
Customizable Forks: Optional
Customizable Mast: Optional
