DC Voltage Output:
Voltage Basic Range: 75mV, 300mV, 1V, 3V, 10V, 30V, 100V, 500V, 1000V
Setting Value Range: Automatically Switch Range Output: 0mV ～ 1100V. Manually Setting Range Output: 0～110%RG
Adjustable Step Value: 0.001%RG
Voltage Output Deviation: 0.0122%RD+0.008%RG
Output Stability: 0.01%/min
Output Load Current: Basic Range of Voltage (1). ≥100V: 20VA. (2). ≤1V: 35mA. (3). The rest: 200mA
DC Current Output:
Current Basic Range: 3µA, 10µA, 30µA, 1mA, 3mA, 10mA, 30mA, 100mA, 300mA, 1A, 5A, 50A
Setting Value Range: Automatically Switch Range Output: 0 ～ 55A; Manually Setting Range Output: 0 ～ 110%RG
Adjustable Step Value: 0.001%RG
Output Current Deviation: 0.012%RD+0.008%RG(I≥1mA) 0.036%RD+0.024%RG(I﹤ 1mA)
Output Stability: 0.01%/min
Output Load Voltage: Range: (1). 100uA ～ 1A: 20V. (2). 5A: 7.5V. (3). 20A: 3V. (4). 50A: 2V
DC Voltage Measurement:
Input Range: 1000V, 100V, 10V, 1V, 100mV
Switch Range: Automatically Switch Range
Measurement Resolution: 0.001%RG
Measurement Deviation: 0.02%RG
DC Current Measurement:
Input Range: 50A, 5A, 1A, 100mA, 10mA, 1mA
Regulating Fineness: Automatically Switch Range
Measurement Resolution: 0.001%RG
Measurement Deviation: 0.02%RG
DC Power Output:
Accuracy of Power Output: 0.02%RG
Other Index:
Temperature Coefficient: ±(0.002%RD+0.001%RG)/℃
Unit Power Consumption: ≤250VA
Net Weight: ≤15kg
Dimension: 423 × 445 × 133mm (W × D × H)
Voltage & Frequency: AC220V±5%, 50±5Hz
Ambient Operation Temperature: 0 ～ 40℃
