Frame capacity: 10T
Load cell brand:
USA brand transcell load cell for high accuracy
10T (2T, 5T are optional)
Load accuracy: 0.5% F.S
Control system: PC with windows 7 system
Motor: Panasonic servo motor w/AC variable speed drive system, high-precision mechanical ball screw rod
Force reading: kgf, Ibf, N, KN, T etc
Vertical test space: 1100mm including fixture
Horizontal test space: ≤400mm
Test speed: 0.1~300mm/min (adjustable)
Software: TM 2101
Curves display: Load- elongation, Elongation-time, Time-elongation, Stress-strain
Data display: Max. force, speed, sample information, strength(Kpa, Mpa, N/mm, N/mm2) etc…
Safety features:
E-Stop
Over-load protection
Upper and lower limit switches
Load sensor with automatic retreat
