Number of Channel: CH1
Voltage: 0 – 36.000V
Current: 0 – 10.0000A
Constant Voltage Operation:
Line Regulation: ≤ 0.01% + 3mV
Load Regulation: ≤ 0.01% + 5mV
Ripple & Noise (5Hz–1MHz): ≤ 2mVrms
Transient Recovery Time: ≤100μs (50% load change, minimum load)
Temperature Coefficient: ≤ 300ppm/°C
Constant Current Operation:
Line Regulation: ≤ 0.01% + 3mA
Load Regulation: ≤ 0.01% + 3mA
Ripple & Noise: ≤ 2mArms
Resolution:
Programming (Voltage/Current): 1mV / 0.2mA
Readback (Voltage/Current): 0.1mV / 0.2mA
Meter:
Full Scale (V/A): 36.5000V / 10.2000A
Programming Resolution: 5 digits / 6 digits
Readback Resolution: 6 digits / 6 digits
Setting Accuracy (Voltage/Current):
Voltage: (0.03% + 10mV)
Current: (0.3% + 10mA)
Readback Accuracy (Voltage/Current):
Voltage: (0.03% + 10mV)
Current: (0.3% + 10mA)
DC Load Mode:
Voltage Range: 1 – 36.50V
Current Range: 0 – 10.200A
Power Range: 0 – 100.00W
CV Mode:
CH1: 1.500V – 36.50V
Accuracy: ≤(0.1% + 30mV), Resolution: 10mV
CC Mode:
CH1: 0 – 10.200A
Accuracy: ≤(0.3% + 10mA), Resolution: 1mA
CR Mode:
CH1: 1Ω – 1kΩ
Accuracy: ≤(3% + 1Ω), Resolution: 1Ω
Protection:
OVP: OFF, ON (0.5V – 38.0V), Accuracy: ±100mV, Resolution: 100mV
OCP: OFF, ON (0.05A – 10.5A), Accuracy: ±20mA, Resolution: 10mA
Insulation Resistance:
Between chassis and terminal: ≥ 20MΩ (DC 500V)
Between chassis and DC power: ≥ 30MΩ (DC 500V)
General:
Environment: Indoor use, Altitude ≤ 2000m
Operating Temp: 0 – 40°C, RH ≤ 80%
Installation category: II, Pollution degree: 2
Storage: -10°C – 70°C, RH ≤ 70%
Power Input: 100/120/220/230V ±10%, 50/60Hz
Power Consumption: 90VA, 68W
Size & Weight: 213(W) × 88(H) × 362(D) mm, Approx. 10kg
