Accessories: Safety Instruction Sheet x 1; Power cord x 1; Test lead GTL-207 x 1; CD x 1
Resolution: 10μV, 100μV, 1mV, 10mV, 100mV
Accuracy: ±0.02%
Resistance: 500Ω, 5kΩ, 50kΩ, 500kΩ, 5MΩ, 50MΩ
Resolution: 10mΩ, 100mΩ, 1Ω, 10Ω, 100Ω, 1kΩ
Accuracy: ±0.1%
DC Current:500μA, 5mA, 50mA, 500m A, 5A, 10A
Resolution: 10nA, 100nA, 1μA, 10μA, 100μA, 1mA
Accuracy: max 0.05% depend on range
Diode Test: 5V, Resolution (100μV) ; Accuracy: 0.05%
Capacitance: 0.5~1nF, 1~5nF, 5~10nF, 10~50nF, 500nF, 5μF, 50μF
Resolution : 0.001nF, 0.001nF, 0.01nF, 0.01nF, 0.1nF, 1nF, 10nF
Accuracy: 2%
Volatge AC ( true RMS): 500mV, 5V, 50V, 500V, 750V
Resolution : 10μV, 100μV, 1mV, 10mV, 100mV
Accuracy: max 0.35% ( depend on range)
Current AC ( true RMS): 500μA, 5mA, 50mA, 500mA, 5A, 10A
Resolution : 10nA, 100nA, 1μA, 10μA, 100μA, 1mA
Accuracy: max 0.5%
Frequency: 10Hz – 500Hz, 500Hz – 500kHz, 500kHz – 1MHz
Accuracy: 0.01%
Max./Min., REL, MX+B, 1/X, Ref%, Compare, Hold, dB, dBm
Interface: USB
Display: VFD, Tow Colors Display
Power : AC 100 V / 120 V / 220 V / 240 V ±10%, 50-60Hz; 15VA
Weight : 2.9kg
Dimensions: 265(W) x 107(H) x 302(D) mm
