Acoustic Sensor
Microphone array: 128 low-noise MEMS microphones
Bandwidth: 0 kHz to 65 kHz, adjustable range
SPL range: 0–120 dB
Frame rate: 30 Hz
Thermal Sensor (Thermal module required)
Detector type: VOx, 640×512 @12 µm
Focal length: 13 mm / 17.7 mm
Measurement range: Supports auto-switching: -40°C to 150°C, 0°C to 650°C
Measurement accuracy: ±2°C or ±2%, whichever is greater
Image Display
Display screen: 10.1" LCD touchscreen, 1920×1200
Digital camera: 13 MP
Others
Laser: Supports laser indication, laser ranging range of 0.1 m to 35 m
Operating time: Built-in battery + external battery: 4 hours
Weight: 1.7 kg to 2 kg (with built-in battery)
Size: 309×243.5×74 mm / 309×243.5×100 mm
UV Sensor
UV sensitivity: 5×10⁻¹⁶ W/cm²
Response band: 200 nm–340 nm
Minimum discharge sensitivity: 1 pc @10 m
Field of View (FOV): 20° (H) × 15° (V)
Focus: Autofocus
Imaging distance: 0.5 m–∞
Image frequency: 25 Hz
Image Display
Image modes: IR, MIF, IR, PIP, UV
Corona glow: Customizable, supports opacity settings
Weight
Ultraviolet module: 324.0 g
Focus-free Thermal & Ultraviolet module: 597.5 g
Autofocus Thermal & Ultraviolet module: 798.5 g
