Input channels voltage / current: 4 / 4
Measurement interval [ #cycles ]: 10/12 (50/60Hz); 1/2
Inputs
Nominal current: 1 … 5 A (max. 7.5A)
Current measurement via Rogowski coils: Yes
Measurement range: 0…3000A (max. 3800A)
Nominal voltage: 57.7 … 400VLN, 100 … 693VLL
Nominal frequency: 42 … 50 … 58Hz, 50.5 … 60 … 69.5Hz
Weight: 600 g
Protection: IP40 (front), IP30 (housing), IP20 (terminals)
Communication
Ethernet: Modbus/TCP, web server, NTP (standard)
IEC61850: Option
PROFINET IO: Option
RS485: Modbus/RTU (standard)
Standard I/Os: 1 dig. IN ; 2 dig. OUT
Extension modules (optional): max. 2 modules
Power supply
Nominal voltage: 100-230V AC/DC or 24-48V DC
UPS (optional): 5 times 3 minutes
Design
Colour display: TFT 3.5“ (320x240px)
