Standards: IEC 61010, EN 61557, DIN VDE 0100, DIN VDE 0105
Applications: Electrical installation testing, commissioning, inspection, troubleshooting, service & maintenance
Measurement Functions:
Voltage: AC/DC up to 1000 V
Current: AC/DC up to 10 A
Frequency: 15.4 Hz – 420 Hz
Resistance: up to 30 MΩ
Continuity: ≥200 mA test current, acoustic signal
Insulation resistance: 50 / 100 / 250 / 500 / 1000 V DC, up to 30 GΩ
Loop impedance: With and without RCD tripping
Earth resistance: Probe & clamp methods
RCD testing: Type AC, A, F, B (standard & selective)
Touch voltage: Measurement & evaluation
Phase sequence test
Automatic Test Sequences: Yes
Display: Large illuminated graphic LCD
Interface: USB (PC communication & data transfer)
Data Memory: Internal measurement memory
Safety Category: CAT IV 300 V / CAT III 600 V
Protection Class: IP40
Power Supply: Rechargeable battery pack
Operating Temperature: –10°C ~ +50°C
Storage Temperature: –20°C ~ +60°C
Dimensions (W × H × D): approx. 240 × 190 × 105 mm
Weight: approx. 1.3 kg
