Insulation resistance measurement range: 0.100 MΩ to 10 GΩ
Insulation test voltage range: 40 V to 1000 V DC, adjustable
Voltage measurement range: 0 V to 600 V AC/DC
Surge protection device (SPD) testing: Varistors and gas discharge tubes with test voltages from 40 V to 1000 V
Display: Backlit color OLED display with digital measurement indication
Touch voltage indication: Automatic detection and warning of dangerous voltage
Protective device database: Integrated table of common varistors for evaluation support
Measurement illumination: Integrated LED for measurement point illumination
Automatic discharge function: Automatic discharge of device under test after insulation measurement
Safety category: CAT III 300 V (with safety cap), CAT II 600 V (without safety cap)
Protection rating: IP40
Operating temperature range: 0°C to +40°C
Power supply: 4 × AAA batteries (1.5 V alkaline or 1.2 V NiMH rechargeable)
Dimensions (W × H × D): Approx. 260 × 70 × 40 mm
Weight: Approx. 0.36 kg (including batteries)
