Capacity, m3/hour / gals. per hour:
• degassing, drying and filtration mode: 2-6
• heating and filtration mode: 2-7
*Processed oil parameters:
• gas content, % vol, max: 0.1
• water content, ppm, max: 10
• ISO 4406 purity class: 16/14/12
Max oil output temperature in heating mode, ºС: 90
Outlet pressure, Mpa: 0.2
Max heater power, kW: 100
Max power consumption, kW: 115
Residual vacuum chamber pressure for seal test, Pa, max: 26.7
Max air leak in 1 hour seal test, Pa: 267
Power supply:
• voltage, V: 400
• frequency, Hz: 50/60
Dimensions, mm (w/o trailer / with trailer):
– length: 2600/3750
– width: 1250/1840
– height: 1500/1940
Weight, kg (w/o trailer / with trailer): 1100/1500
* Note – Initial oil quality parameters:
• gas content: below 10.5% vol
• water content: below 0.005% (50 g/t)
• temperature: above 0 ºС.
