Mill capacity, m3/h (gpm): 8… 16 (35… 70)
Kinematic viscosity of product, mm2/s (St), not more than: 150 (1.5)
Initial size of polymer particles, mm (in), not more than: 5 (0.2)
Maximum operating pressure, MPa (psi): 0.6 (87)
Rated rotation frequency, rpm: 2,950
Drive motor power, kW: 75
Parameters of electricity mains, V/Hz: custom
Nominal bore diameter of mill fittings, mm (in)
– inlet: 120 (4.7)
– outlet: 80 (3.1)
Operating temperature, °С (°F), not more than: 180 (356)
Mill shaft seal: packing
Knife gap adjustment type: manual
Knife gap adjustment range, mm (in): 0,2…2 (8·10-3… 8·10-3)
Knife tip speed at 3,000 rpm, m/s (mph), not more than: 47 (105)
Dimensions (not more than), mm (in):
– length: 1,690 (67)
– width: 650 (26)
– height: 770 (30)
Net weight (not more than), kg (lb): 780 (1,720)
