Optical system: Collimated light, diffuse vision, integrating sphere receiving mode
Size of sample window: In the window: Æ25mm, Out the window: Æ21mm
Light source: light Source C (6774K), Light Source A (2856K)
Receiver: Silicon Light Battery
Electronic System: Large LCD touch screen
Minimum reading: Transmittance 0.01%, Haze 0.01%
USB interface, U-disk storage function
Measurement Range: Transmittance 0%-100.0%; Haze 0%-30.00%
Sample size:
Solid sample size: 50mm×50mm
Tank size: 50mm×50mm×10mm
Film sample size: 50mm×50mm
Calibration Sample: Æ40mm×2mm (one piece)
Machine Size: 740mm×270mm×300mm
Weight: 21kg
Power: 220V±22V 50Hz±1 Hz (Specified by user)
Environment condition: 5℃~35℃
Transmittance accuracy: ≤1%
Haze Accuracy: ≤±0.1％, when haze ≤ 0.5％; ≤±0.3％, when haze＞0.5％
Translucent Repeatability: 0.5%
Haze Repeatability: 0.05％ when haze ≤ 0.5％; 0.1％, when haze＞0.5％
Optional Accessories: Calibration Sample
