Laser diode: red
Self-levelling range: ± 8°
Accuracy horizontal: ± 0,5 mm / 10 m
Accuracy vertical: ± 1,0 mm / 10 m
Working range without receiver: Ø 40 m
Working area with FR 77-MM: Ø 400 m
Working range remote control: 150 m
Grade: digital
Horizontal slope setting x-Axis: ± 10.000%
Horizontal slope setting Y-Axis: ± 10.000%
Vertical slope setting X axis: ± 10,000 %
Vertical slope setting Y(Z) axis: horizontal self-levelled
X and Y-Axis: ∑ ± 14 %
Laser class: 2
Rotating speed rpm: 300, 600, 1100
Operating time: 40 h
Power supply: Li-Ion, intelligent, Alkaline
Dust / water protection: IP 66
Weight (instrument only): 3,85 kg
Remote control channels: 9
Rotating w/o receiver Ø: Ø 40 m, Ø 60 m
Scanning w/o receiver : 60 m (radius)
Scanning range: 0°, 10°, 45°, 90°, 180°
Temperature range: -10°C to +50°C
Supplied with:
· Receiver FR 77-DIST 30 with clamp
· 2-Way RF Remote control
· Li-Ion battery & charger
· Vertical mount
· Telescope
· 360° horizontal fine adjustment bracket
· Container
