DC voltage: 0.1 mV to 1000 V/±0.05 % + 1
AC voltage: 0,1 mV to 1000 V/ ±0,7 % +4
DC current: 0,1 μA to 10 A/ ±0,2 % + 4
AC current: 0,1 μA to 10 A/ ±1,0 % + 2
Resistance: 0,1 Ω to 50 MΩ/ ±(0,2 % + 1)
Conductance: 60,00 nS/ ± (1,0 % + 10)
Diode Test: 2,0 V/ ± (2,0 % + 1)
Duty Cycle: 0,0 % to 99,9 %/ ±(0,2 % trên kHz + 0,1 %)
Display counts: 6000 counts/19,999 counts in high-resolution mode
Capacitance: 10 nF to 9999 μF/ ± (1,0 % + 2)
Frequency: 0,5 Hz to 199,99 kHz/ ± (0,005 % + 1)
Temperature: -200 °C to +1090 °C/ ± (1,0 % + 10) °C
Peak Capture: Record transients up to 250 us
Min/Max/Avg Recording: Display signals up to approximately 100 ms
| Basic Accuracy Specifications | |||||
| Accuracy specifications are shown as +/- (% of reading + number of digits) | |||||
| DC voltage |
|
||||
| AC voltage |
|
||||
| DC current |
|
||||
| AC current |
|
||||
| Resistance |
|
||||
| Conductance |
|
||||
| Diode Test |
|
||||
| Duty Cycle |
|
||||
| Display counts |
|
||||
| Capacitance |
|
||||
| Frequency |
|
||||
| Temperature |
|
||||
| Peak Capture |
|
||||
| Min/Max/Avg Recording |
|
||||
| Safety Certifications | |||||||
| ATEX |
|
||||||
| NEC-500 |
|
||||||
| IEXEx |
|
||||||
| GOST R Ex (Pending) |
|
||||||
| General Specifications | |||||
| Power |
|
||||
| Display |
|
||||
| External protection |
|
||||
| Warranty |
|
||||
| Size with holster (HxWxL) |
|
||||
| Weight with holster |
|
||||
