IR resolution: 160×120(19,200pixels)
Refresh rate: 9Hz
Thermal sensitivity/NETD: <100mK@86°F(30°C)
Field of view (FOV): 47° ×35°
Focal plane array: Uncooled microbolometer, 7.5~13µm
Start-up time: <30sec (IRimage, no GUI)
Visual cameradata
Built-in digital camera: 640×480(307,200pixels)
Field of view (FOV): 73° ×61°, adapts to IRlens
Sensitivity: Minimum10lux
Imagepresentation
Display: 320×240pixel, 3in backlit LCD
Auto-range: Auto, non-selectable
Measurement
Object temperature range: -4°F to 302°F (-20°C to 150°C); 32°F to 932°F (0°C to 500°C)
Accuracy: ±7.2°F (±4°C) or ±4%of reading for
ambient temperature 50°F to 95°F (10°C to 35°C)
Datatransfer and compatibility
USB type: USB micro-B
Interfaces: Update from PC devices
Compatibility: Works with FLIR Tools software
Operating temperature range: 14°F to 131°F(-10°C to 55°C) - infinity; 185°F (85°C) - 15minutes; 302°F (150°C) - 10minutes; 500°F (260°C) - 3 minutes
Storage temperature range: -40°F to 158°F (-40°C to 70°C)
Battery type and voltage: Li-ion, 3.6Vrechargeable
Battery operating time: Approximately 4hours at 77°F(25°C) and with typical use
Charging time: 2.5h to 90%capacity
Power management :Automatic shutdown and sleep mode
Encapsulation: IP67(IEC60529)
Weight w/ battery: 1.54lbs (0.7kg)
Size (L×W ×H): 9.8×4.1×3.5 in
Tripod mount: UNC1/4"-20
