Imaging & Optical
IR Resolution: 320 × 240 pixels
Thermal Sensitivity/NETD: 15 mK at 30°C (86°F)
Detector Type: Focal plane array (FPA), cooled QWIP
Spectral Range: 8.0 µm to 8.6 µm
Detector Pitch: 30 µm
Sensor Cooling: Stirling Microcooler (FLIR MC-3)
Digital Image Enhancement: High sensitivity mode (HSM), noise reduction filter
Available Lenses: 24° × 18° (23 mm)
F-Number: 1.59
Focus: Autofocus, Manual focus
Image Presentation
Display: 4", 640 × 480 pixel rotatable, touchscreen LCD
Viewfinder: Built-in, tiltable OLED, 800 × 480 pixels
Image Presentation Modes: IR image, visual image, high sensitivity mode (HSM)
Color Palettes: Arctic, White hot, Black hot, Iron, Lava, Rainbow, Rainbow HC
Zoom: 1–8× continuous, digital zoom
Laser Pointer: Class 2
Measurement & Analysis
Measurement Temperature Range: -20°C to 250°C (-4°F to 482°F)
Accuracy: ±1°C (±1.8°F) for temperature range (0°C to 100°C, 32°F to 212°F) or ±2% of reading for temperature range (>100°C, >212°F)
Image Analysis: 10 spots, 5 boxes with max/min/average, 1 line (horizontal or vertical), measurement corrections
Annotations
Voice: 60 seconds with Bluetooth on still images and video
Text: Text from predefined list or soft keyboard on touchscreen
Image Sketch: Yes: on infrared only
Communication & Data Storage
FLIR Inspection Route: Enabled in the camera
MultiREC Recording: Record multiple files automatically in customizable order
GPS: Location data automatically added to every still image; first frame in video from built-in GPS; data logging feature
Compass: Yes
Cloud Services (via Wi-fi): FLIR Ignite for direct, secure image uploading, organizing, storage, and sharing (required firmware available)
Storage Media: Removable SD card
Image File Formats: Standard JPEG, measurement data included. Infrared-only mode.
Communication Interfaces: USB 2.0, Bluetooth via headset, Wi-Fi, HDMI
Video Out: HDMI; DVI
Video Recording and Streaming
Radiometric IR Video Recording: RTRR (.csq)
Non-Radiometric IR or Visual Video: H.264 to memory card
Radiometric IR Video Streaming: Over UVC
Non-Radiometric IR Video Streaming: H.264 (AVC) or MPEG4 over RTSP (Wi-Fi); MJPEG over UVC and RTSP (Wi-Fi)
Visual Recording: H.264 to memory card
Environmental & Certifications
Operating Temperature Range: -20°C to 50°C (-4°F to 122°F)
Storage Temperature Range: -30°C to 60°C (-22°F to 140°F)
Encapsulation: IP54 (IEC 60529)
Shock: 25 g (IEC 60068-2-27)
Vibration: 2 g (IEC 60068-2-6)
Additional Information
Battery Type: Rechargeable Li-ion battery; 7.4 V, charged in camera or separate 2-bay charger
Battery Operating Time: >2.5 hours at 25°C (68°F) and typical use
Battery Charging Time: 2.5 hours to 95% capacity, charging status indicated by LEDs
Camera Size: 251.6 mm × 164.5 mm × 170.9 mm (9.9 in × 6.48 in × 6.73 in)
Camera Weight: 3 kg (6.18 lb)
Mounting Interfaces: UNC ¼"-20
