Digital I/O connector type: 12-pole M12 connector (shared with Digital Synchronization and External power)
Digital Inputs: 1× opto-isolated, "0" <1.2 VDC, "1" = 2–25 VDC.
Digital Output Purpose: General purpose output to ext. device (programmatically set)
Digital Outputs: 1× opto-isolated, 2–40 VDC, max 185 mA
EMC: •EN 61000-6-2 (Immunity) •EN 61000-6-3 (Emission) •FCC 47 CFR Part 15 Class B (Emission)
f-number: 1.4
Image Frequency: 60 Hz
Thermal Sensitivity/NETD: <0.05°C @ 30°C (86°F) / 50 mK
Accuracy: ±5°C (±9°F) or ±5% of reading
Communication & Data Storage
Digital I/O connector type: 12-pole M12 connector (shared with Digital Synchronization and External power)
Digital I/O isolation voltage: 500 VRMS
Digital I/O supply voltage: 2–40 VDC, max 200 mA
Digital Inputs: 1× opto-isolated, "0" <1.2 VDC, "1" = 2–25 VDC.
Digital Output Purpose: General purpose output to ext. device (programmatically set)
Digital Outputs: 1× opto-isolated, 2–40 VDC, max 185 mA
Digital Synchronization Connector Type: 12-pole M12 connector (shared with Digital I/O and External power)
Ethernet: Control and image
Ethernet Communication: GigE Vision ver. 1.2 Client API GenICam compliant
Ethernet Connector Type: RJ-45
Ethernet Image Streaming: 8-bit monochrome @ 60 Hz Signal linear/ DDE Automatic/ Manual Flip H&V 14-bit 320 × 256 pixels @ 60 Hz Signal linear/ DDE Temperature linear GigE Vision and GenICam compatible
Ethernet Power: Power over Ethernet, PoE IEEE 802.3af class 0 Power
Ethernet Protocols: TCP, UDP, ICMP, IGMP, DHCP, GigEVision
Ethernet Standard: IEEE 802.3
Ethernet Type: Gigabit Ethernet
Synchronization in: 1×, non-isolated
Synchronization in - purpose: Frame sync in to control camera
Synchronization in - type: LVC Buffer @3.3V, "0" <0.8 V, "1" >2.0 V.
Synchronization out: 1×, non-isolated
Synchronization out - purpose: Frame sync out to control another Ax5 camera
Synchronization Out - type: LVC Buffer @ 3.3V, "0"=24 MA max, "1"= –24 mA max.
Imaging & Optical
Detector Pitch: 17 µm
Detector Time Constant: Typical 12 ms
Detector Type: Focal plane array (FPA), uncooled VOX microbolometer
Field of view (FOV): 45° × 35°
FLIR Screen-EST Mode: No
f-number: 1.4
Focal Length: 7.5 mm (0.30 in.)
Focus: Fixed
Image Frequency: 60 Hz
IR Resolution: 320 × 256 pixels
Minimum Focus Distance: 2.5 cm (0.98 in.)
Spatial resolution (IFOV): 2.267 mrad
Spectral Range: 7.5–13 µm
Thermal Sensitivity/NETD: <0.05°C @ 30°C (86°F) / 50 mK
Measurement & Analysis
Accuracy: ±5°C (±9°F) or ±5% of reading
Atmospheric transmission correction: Automatic, based on inputs for distance, atmospheric temperature and relative humidity
Camera size (L x W x H): 104.1 × 49.6 × 46.6 mm (4.1 × 1.9 × 1.8 in.)
Emissivity Correction: Variable from 0.5 to 1.0
Measurement Corrections: Global object parameters
Object Temperature Range: -25°C to 135°C (-13 to 275°F) / –40°C to 550°C (-40 to 1022°F)
Optics Transmission Correction: Automatic, based on signals from internal sensors
Reflected apparent temperature correction: Automatic, based on input of reflected temperature
General
Base Mounting : 4 × M3 thread mounting holes (bottom)
Housing material: Magnesium and aluminum
Package Includes: Hard transport case; Infrared camera with lens; Base support; Cable tie (2 ea.); Ethernet cable CAT-6, 2m/6.6 ft (2 ea.); FLIR ResearchIR Standard 4 Focus adjustment tool; Gooseneck Mains cable kit (UK,EU,US); PoE Injector (power over Ethernet); Printed documentation Table stand
Packaging Size: Cardboard box
Environmental
EMC: •EN 61000-6-2 (Immunity) •EN 61000-6-3 (Emission) •FCC 47 CFR Part 15 Class B (Emission)
Encapsulation: IP 40 (IEC 60529) with base support mounted
Humidity (Operating and Storage): IEC 60068-2-30/24 h 95% relative humidity 25°C to 40°C (77°F to 104°F)
Operating Temperature Range: –15°C to +50°C (+5°F to +122°F) The operating temperature range assumes that the camera is mounted on the base support (included in the package) or a similar type of heatsink.
Shock: 25 g (IEC 60068-2-27)
Storage Temperature Range: –40°C to 70°C (–40°F to 158°F)
Tripod Mounting: UNC ¼"-20 (on three sides)
Vibration: 2 g (IEC 60068-2-6 & MIL-STD810G)
Power
External Power Connector Type: 12-pole M12 connector (shared with Digital I/O and Digital Synchronization )
External Power Operation: 12/24 VDC, < 3.5 W nominal < 6.0 W absolute max
Voltage: Allowed range 10–30 VDC
