- NEMA Environment Type: Type 4/12 (outdoor/indoor)
- Maximum Operating Temperature: 500°F/260°C
- Crystal Insert Diameter: 50mm (1.97")
- Viewing Aperture Diameter: 45mm (1.77")
- Viewing Aperture Area: 1590mm2 (2.46in2)
- Window Thickness: 2mm (0.07")
- Optic Maximum Temperature: 1355.6°C (2474°F)
- Voltage Range: Any
- Body Material: Anodized Aluminum
- Overall Height: 85.5mm (3.36")
- Overall Width: 73mm (2.87")
- Overall Thickness: 25.5mm (1.00")
- Required Hole Diameter(Nominal): 2-3/8" (60.3mm)
- Greenlee Punch: 76BB
- Broadband IR -- Short-, Mid-, & Longwave: Yes
- Visible Light Spectrum: Yes
- Picture-in-Picture & Fusion Image Blending: Yes
- Underwriters Laboratories(UL 50V): Yes
- UL 50 Environment: Type 4/12
- CSA Certification, Product Class 3211 07: Yes
- KEMA (IEC 62271-200): Arc flash test standard: 5kV, 63kA for 30 cycles at 60Hz
- TUV (IEC 60529): IP67
- TUV (IEC 60068-2-6): 100 m/s^2 vibration withstand
- TUV (IEC 60068-2-3): 15-day extreme humidity withstand
- TUV (ANSI/IEEE C37.20.2 section A3.6): Impact Resistant Cover
- Maximum Pullout Strength: 657 kg(1450 lbs)
