Specification: 120V/7.5A/900W
Voltage resolution: 10mV
Current resolution: 1mA
Redundant output range: 121V/7.6A/900W
CV mode
Source effect: ≤ 0.01 %+ 4mV
Load effect: ≤ 0.1 %+ 5mV
Recover time: ≤1.5 ms (50% load change)
Ripple nosie: 2mVrms, 30mVpp
Temperature coefficient: ≤ 100 ppm / ℃
Design accuracy: ±(0.03% of reading+10mV)(25±5℃)
Design resolution: 1mV
CC mode
Source effect: ≤0.1%+ 3 mA
Load effect: ≤ 0.1%+ 5 mA
Ripple noise: ≤10mArms
Design accuracy: ±(0.1% of reading+0.1% F.S.)(25±5℃)
Design resolution: 1mA
Readback
Voltage: 5 digits display
Current: 5 digits display
Voltage resolution: 1mV
Current resolution: 1mA
Voltage accuracy: ±(0.02% of reading+5mV)(25±5℃)
Current accuracy: ±(0.1% of reading+0.1% of F.S.)(25±5℃)
Protection: OCP, OVP, OPP, OTP, reverse polarity protection, etc.
Keypad lock: Support
Interface: Standard RS232, support SCPI (optional analog control interface, RS485, LAN, MODBUS)
Storage & recall: 100 Groups
Input: AC220V±% , 50/60Hz
Size: 352 (D) × 215 (W) × 89 (H) mm
Weight: 4.5~5.5kg
