Output Voltage: 0~ 600V
Current: 0~ 17A
Power: 10kW
Dimension (mm): 482.6(W)*132.5(H)*600(L)
Weight: 25kg
AC Input: 3 Phase input, 340VAC ~ 420VAC, 47Hz ~ 63Hz
Output Voltage: 0 ~ rated voltage (Max 1500V)
Output Current: 0 ~ rated current (Max 1200A)
Output Power: 0 ~ rated power
Efficiency: 0.87 (Typical)
Line Regulation: Voltage: 0.01%F.S.; Current: 0.05%F.S.
Load Regulation: Voltage: 0.02%F.S.; Current: 0.1%F.S.
Analog Programming: V/I control; Support programming voltage: DC 0 ~ 5V/DC 0 ~ 10V input
Voltage Measurement Accuracy: 0.1%+0.1%F.S.
Current Measurement Accuracy: 0.1%+0.2%F.S.
Voltage & Current Monitoring: Voltage/Current monitoring output voltage: DC 0 ~ 10V
Protection: OVP/OCP/OPP/RVP/LVP/OTP
Transient Response: Typical 1ms
Voltage Temperature Coefficient: 20ppm/℃
Current Temperature Coefficient: 40ppm/℃
Display: 4.3’’ TFT color LCD
Operation: Function key, number key, and knobs
Communication Ports: Standard RS232, LAN
Storage: 20 groups of fast recall parameters +8 sequence files
Cooling: Air cooling
Working Temperature: 0℃ ~ 40℃
Storage Temperature: -20℃ ~ 70℃
Altitude: <2000m
