Width: 5.7 mm
Height: 26.7 mm
Length: 15.7 mm
Fall Time: 85 ns
Rise Time: 130 ns
Technology: Si
Unit Weight: 7 g
Channel Mode: Enhancement
Configuration: Single
Mounting Style: Through Hole
Transistor Type: 1 N-Channel
Qg - Gate Charge: 80 nC
Number of Channels: 1 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 120 W
Vgs - Gate-Source Voltage: - 30 V, + 30 V
Typical Turn-On Delay Time: 60 ns
Typical Turn-Off Delay Time: 130 ns
Id - Continuous Drain Current: 7.2 A
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Rds On - Drain-Source Resistance: 1.1 Ohms
Vds - Drain-Source Breakdown Voltage: 900 V
Vgs th - Gate-Source Threshold Voltage: 3 V
