Width: 5 mm
Height: 1.1 mm
Length: 6 mm
Fall Time: 6 ns
Rise Time: 15 ns
Technology: Si
Unit Weight: 68.100 mg
Channel Mode: Enhancement
REACH - SVHC: Details
Configuration: Single
Mounting Style: SMD/SMT
Transistor Type: 1 N-Channel
Qg - Gate Charge: 75 nC
Number of Channels: 1 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 2.5 W
Vgs - Gate-Source Voltage: - 20 V, + 20 V
Typical Turn-On Delay Time: 25 ns
Typical Turn-Off Delay Time: 32 ns
Id - Continuous Drain Current: 8.9 A
Maximum Operating Temperature: + 155 C
Minimum Operating Temperature: - 55 C
Rds On - Drain-Source Resistance: 14.8 mOhms
Vds - Drain-Source Breakdown Voltage: 100 V
Vgs th - Gate-Source Threshold Voltage: 2.5 V
