HWF 10x/22 mm eyepieces
Trinocular head, 30° inclined tubes. Tubes can be positioned in upper or lower positions
Interpupillary distance 48-75 mm
Diopter adjustment on both eyepieces
Reversed quintuple revolving nosepiece on ball-bearings
LWD M-plan 5x, 10x, 20x IOS infinity corrected objectives and LWD M-plan semiapochromatic 50x IOS infinity corrected objective.
All optics are anti-fungus treated and anti-reflection coated for maximum light throughput
150 x 140 mm stage with 76 x 50 mm mechanical stage
Coaxial coarse and fine adjustments with 200 graduations. Precision 1 μm, 0.2 mm per rotation. Total travel approximately 28 mm
Height adjustable Abbe condenser N.A. 1.25 with iris diaphragm and filter holder
Condenser with slot for optional slider with darkfield or phase contrast
Diascopic 3 W NeoLED™ Köhler illumination with adjustable intensity with internal power supply 100-240 V (CE)
Reflected 3 W NeoLED™ Köhler epi-illumination attachment with external power supply.
Supplied with blue, green and white balance filter mounted in slider
Standard: Supplied with analyzer and rotatable polarizer. Oblique illumination
Supplied with power cord and dust cover in styrofoam case
