HWF 10x/25 mm eyepieces
Trinocular head, 45° inclined tubes with 100-0/20-80/0-100 beamsplitters
Interpupillary distance 47-78 mm. Diopter adjustment on both eyepieces
Reversed sextuple revolving nosepiece on ball-bearings
Plan Phase Semi Apochromatic Fluarex PLPH-SAFi 10x/20x/S40x IOS infinity corrected objectives with 1.2 mm cover glass correction. M25 thread
All optics are anti-fungus treated and anti-reflection coated for maximum light throughput
340 x 230 mm stage with 130 x 85 mm mechanical X-Y stage
Coaxial coarse and fine adjustments with 200 graduations. Precision 1 μm, 0.2 mm per rotation. Total travel approximately 10 mm
Rotating multi-function condenser N.A. 0.55 with iris diaphragm and filter holder. Working distance 26 mm. Supplied with phase contrast annuli for 10x, 20x and 40x objectives and DIC prepared. Need additional DIC prisms. The arm of condenser can be backwards tilted for convenient access to the stage.
Lens changer with 1.5x magnification lens for intermediary magnifications without refocusing.
Standard supplied with the fluorescence filter set wheel with two standard fluorescence filters for blue excitation EX 460-495 nm (BP) DM 505 EM 510 nm (LP) and green excitation EX 510-550 nm (BP) DM 570 EM 575 (LP).
Transmitted 10 W NeoLED™ with adjustable intensity and internal power supply 100-240 V (CE) and 100 W mercury vapor HBO lamp for fluorescence
Supplied with metal insert for 38 and 54 mm diameter cell culture dishes and 76 x 26 mm slides, metal insert for Multiwell plates and Terasaki plate, blue and green filters, alignment telescope, power supply for fluorescence 100 W HBO mercury vapor lamp and power cord
