Technical Specifications:
Available diameters[mm]: 25, 40, 50, 65, 80, 100, 125, 150, 200. 250, 300
Joints: coupling flanges : EN1092-1, ANSI 150, ANSI 300, ANSI 600, ANSI 900, DIN 2501, BS 4504, AS 2129 (TABLE D - E - F), AS 4087, ISO 7005-1, KS 10K
Maximum pressure: 40 bar for diameters < DN150 / 16 bar for diameters > DN200
Internal lining and liquid temperature (Compact version Tmax 80°C.)
Internal lining: PTFE / liquid temperature: Standard -40 /+130°C (up to +180° on request)
Internal lining: Ebonite / liquid temperature:-40°C / +80°C
Degree of protection: IP68 continuous immersion at a 1,5 m (EN 60529)
Compatible converters: MC608 A/B/R/P/I, MC406
Electric connections: Cable glands M20 x 1.5 + terminal block + sealing resin
