Range
DC 0.0A~2000A
AC 0.0A~1500A
Resolution: AC/DC 0.0A
Max Accuracy: ±2%rdg±5dgt
CT Size: Φ70mm
Meter Dimension: 237mmX131mmX40mm
Weight: 477g
Power Supply: Rechargeable lithium battery DC3.7V/1000mAh
LCD Size: 43mmX38mm; display area: 36.5mmX29mm
LCD Backlight: Yes
Spotlight: Yes
Max/Min Value: Yes
Average Value: Yes
Data Hold: Yes
Data Store: 2000groups (Store with APP)
Overflow Display: Exceed measure range overflow function: “OL ” symbol display
Bluetooth Communication: Yes, can test or view the test results on mobile after installing the APP.
Automatic Shutdown: 5 minutes without any operation after starting up, will shutdown automatically to reduce the power consumption.
Working Current: 60mA (open spotlight 72mA)
Line Voltage: Circuit line test below 600V
Working Condition: -10℃~50℃; below 80%RH
Dielectric Strength: AC 3700V/rms(between the core and shell)
Accessories: Meter: 1PCS; Charge adaptor: 1set; Tool bag: 1PCS
