Measuring Current : 10A, 5A, 1A, 200mA, 40mA, ＜5mA
Measuring Range: 0.5mΩ-0.1Ω (10A); 0.03Ω-1Ω (5A); 0.06Ω-5Ω (1A); 0.1Ω-50Ω (200mA); 0.3Ω-200Ω (40mA); 100Ω-100kΩ (<5mA)
Measuring Accuracy : 0.2%±2μΩ
Resolution : 0.1μΩ
Power Supply : 12V / 6Ah lithium battery
Working temperature : -20 ～ 40 ℃
Ambient humidity : ≤80% RH, no condensation
Oversize : 323*275*135mm (L*W*H)
Weight : 5.0 kg (Including test leads)
Packing List
1 Tester 1 Pc
2 Test Leads 1 Set
3 Charger 1 Pc
4 Reference Resistor 1 Pc
5 Grounding Wire 1 Pc
6 User’s Guide 1 Pc
7 Factory Calibration Cert 1 Pc
8 Warranty Cert 1 Pc
Features:
➢ Large output current and light weight.
➢ 6 output current options, and the maximum output current is 10A.
➢ Can convert the resistance temperature according to the set temperature.
➢ It has perfect protection circuit and more reliable performance.
➢ Lithium-ion battery power supply, easy to operate on site.
➢ It has sound discharge alarm to reduce misoperation.
➢ 4.3-inch color LCD with 480 resolution × 272 TFT true color display.
➢ Adopts machine line integration mode, with built-in test line, which is easy to carry.
➢ Large storage capacity, and can store up to 200 test records.
➢ With USB interface, test data can be transferred to U disk.
➢ The parameter setting is more perfect, which can set the transformer test winding, tap position, test phase, test object temperature, converted temperature value, etc.
