REPLACE MODEL: Associated Research Hypot 3855
INPUT RATING
• Voltage (AC): 100 - 120Vac / 200 - 240Vac±10% Auto Range
• Apparent Power: 360 VA
• Frequency: 50/60 Hz ± 5%
AC WITHSTAND VOLTAGE
• Output Rating: 5KVAC / 20mA
• Output Voltage Range: 0 - 5.00 kVac
• Voltage Resolution: 0.01 kVac
• Voltage Accuracy: (1% of setting + 0.5% of Range)
• Current Measurement Range: 0.000 - 20.00 mA
• Current Resolution: 0.001 / 0.01 mA
• Current Accuracy: (1% of reading + 1% of Range)
INSULATION RESISTANCE
• Output Rating: 1KVDC / 50 Gї
• Output Voltage Range: 30 - 1 KVdc
• Voltage Resolution: 1 Vdc
• Voltage Accuracy: (1% of setting + 0.5% of Range)
• Resistance Measurement Range: 0.100 Mї - 50 Gї
• Resistance Resolution: 0.001 / 0.01 / 0.1 /1 Mї
• Resistance Accuracy:
0.100 - 999.9 MΩ under 30-499V: ±(7% of reading+0.1% of Range)
1 - 10 GΩ under 30-499V: ±(15% of reading+0.1% of Range)
0.500 - 999.9 MΩ under 500-1000V: ±(2% of reading+0.1% of Range)
1 - 9.999 GΩ under 500-1000V: ±(5% of reading+0.1% of Range)
10 - 50 GΩ under 500-1000V: ±(15% of reading+0.1% of Range)
GENERAL
• Interface: USB, PLC Remote
• Display: 4.3" Color Display (Touch Panel)
• Environment: 0 - 40°C, 20 - 80%RH
• Dimension (W x H x D), mm: 215 x 88.1 x 300
• Net Weight: 5.46 Kg
