Operating temperature: 1.2mm-225mm with 5MHz transducer 5mm-3mm with 2MHz transducer
Operating temperature: -10C to 60C
Lower limit steel pipes: dia.20mmx3mm
Display resolution(selectable): 0.1mm / 0.01mm or 0.01inch / 0.001inch
Sound Velocity Range: 1000m/s~9999m/s(0.039~0.394in/μs
Measuring accuracy: ±1%Thickness+0.1mm
Power Source: 2pcs 1.5V AA size,batteries
Battery life: 250 hours typical operating time(LED backlight off)
Weight: 370g
Outline Dimensions: 152mm*74mm*35mm
Data output: RS232 interface for printer or pc
Transducer:
TSTU32: 5.0 to 300.0mm (steel); 22mm; 2MHz; -10C to 60C
5PØ10: 1.2-225.0mm (steel); 10mm; 5MHz; -10C to 60C
Packing list:
Main unit 1
Transducer 5PØ10 1
Ultrasonic couplant 1
Batteries AA 1.5V 2
Instruction manual 1
Carrying case 1
