Output voltage: 0~60V
Output current: 0~3A
Stabilized Voltage status: Voltage stability：≤0.1%±3mV; Load stability：≤0.1%±3mA
Stabilized Current status: Current stability：≤0.1%±3mV Load stability：≤0.1%±3mA
Display accuracy : Voltage：0.5%±3readings Current：0.5%±3 readings
Ripple and noise: VPP≤1%
Display Resolution: Voltage：max 10mV; Current：Max 1mA; Power：Max 10mW
Display method: 4 digits red LED display, 0.40 inches
Power supply: AC 220V±10% /50Hz or AC 110V±10% /60Hz(if 110V, users need to talk to factory in advance)
Operation environment: Indoor，attitude：<=2000m，temperature：5~40℃，humidity：10~85%RH
Storage environment: Temperature：-20~80℃，humidity：<=80%RH
Dimension: 190mm* 70mm* 130mm （L*W*H）
Net weight 1.1kg
Fuse specification: 3A
Note: The above parameters are measured at the ambient temperature of 25±5℃, relative humidity <80%RH, and preheating for 30 minutes. Actual parameters may vary slightly.
Accessories:
Use manual × 1
Qualified certificate × 1
Power plug × 1
Communication:
Communication parameter:
Baud rate：9600
Start bit：1
Data bit：8
Calibration bit：/
Stop bit：1
Footer：0x0A(newline) or 0x0D0A(CRLF)
Cable connection: The product provides users with RS232 communication mode. The DB9 female connector has two TXD pins, three RXD pins, and five GND pins.
