Power：610W
Number of channels: Triple channels: CH1 and CH2 channels are continuously adjustable, CH3 channel has a fixed output
CH1 adjust: 30V/10A
CH2 adjust: 30V/10A
CH3 fixed：5V/2A
Fixed output channel:
Output accuracy: ≤0.1%
Load regulation: ≤1%
Ripple and noise: ≤1%
Adjustable output channels:
Constant voltage output:
Voltage Regulation≤0.1%Umax+5mV
Load Regulation≤0.1%Umax+5mV
Voltage setting accuracy：0.03% + 10mV（25±5℃）
Constant current output:
Power Regulation≤0.2%+3mA
Load Regulation≤0.2%+5mA
Current setting accuracy：0.03% Imax+ 10mA（25±5℃）
Display accuracy（±Output Percent±count）: voltage：0.02% Umax+5mV; current：0.05%Imax +10mA
Display resolution:voltage：1mV； current ：1mA
Protection: Overload protection, reverse polarity protection, overvoltage protection, overcurrent protection, over temperature protection
Power Input: AC 220V±10% /50Hz or AC 110V±10% /60Hz（Toggle Switch）
Communication interface: USB,RS232
Operating environment: Indoor use, altitude：<=2000m，temperature：0~40℃，humidity：10~80%RH
Storage environment: temperature：-20~80℃，humidity：<=70%RH
Dimensions: 356mm* 210mm* 100mm
Product weight: 3kg
