Max Output Power: 615W
Number of Channels: 3 (CH1 and CH2 are adjustable, with CH3 featuring a fixed output of 5V/3A）
DC Output (0~40℃):
Output Voltage (rated value):0~100V
Output Current (rated value): 0~3A
Fixed Output of 5V/3A:
Output Accuracy: ≤0.1%
Load Regulation: ≤1%
Ripple and Noise: ≤1%
(Note: Fixed output parameters have been listed; the following parameters apply to adjustable settings.)
CV State(±Output Percentage ± Number of Words): Voltage Stability: ≤0.1%FS±3; Load Stability: ≤0.1%FS±3
CC State (±Output Percentage ±Number of Words): Current Stability: ≤0.1%FS±3; Load Stability: ≤0.1%FS±3
Display Accuracy (±Output Percentage±Number of Words): Voltage: 0.5%FS±3; Current: 0.5%FS±3
Ripple and Noise: VPP≤0.5%FS
Display Resolution: Voltage: 10mV; Current: 1mA
Display Method: 4-digit red LED digital tube, 0.56 inches
Power Input: AC 220V±10% /50Hz or AC 110V±10% /60Hz (Switch)
Operating Environment: Indoors where altitude: <=2000m, temperature: 0~40℃ and humidity: 10~80%RH
Storage Environment: Temperature: -20~80℃, humidity: <=70%RH
Dimensions: 300mm* 265mm* 150mm (L*W*H)
Product Weight: Net Weight: 3.6kg
