Features:
AC-DC output voltage
AC-DC current output
Analog resistance output
Analog capacitance output
Current output 10A
Fixed frequency output
Measuring range:
Dc voltage output range 0V~±1020V
Ac voltage output range 10mV~760V
Ac current output range 10Aµ~20A (10A selection)
Dc current output range 0~±20A (10A selection)
Resistance value output range 10~220MΩ
Capacitance value output range 5nF ~ 11mF
Fixed frequency points 40Hz, 50Hz, 60Hz, 400Hz, 1000Hz
Continuous frequency output range 10Hz~100kHz (2kHz selection)
Technical performance:
AC stability: < 0.02% of full scale /5 min
DC stability: < 0.01% of full scale /5 minutes
Minimum resolution: 10ppm (0.001%)
Ac distortion degree: <0.5%
Dc ripple coefficient: <0.2%
Frequency output accuracy: <0.1% (continuous)
General performance:
Power supply index: AC power supply voltage 220V±10%, frequency 50Hz±1Hz;
Working environment: working environment temperature 5℃ ~ 35℃, relative humidity <80%;
Dimensions: Length × width × height 420×450×180 (mm)
Weight: Total weight approx. 25kg (selection)
