Input AC : 90...264 V, 45...66 Hz, PF = 0.99
Output voltage : Output 1+2: 0...84 V Output 3: 3...6 V
- Load regulation 0-100% load : <0.15%
- Line regulation ±10% ΔUAC : <0.02%
- Ripple output 1+2 (1 : <96 mVPP / <24 mVRMS
- Regulation 10-90% load : <2 ms
- Overvoltage protection : 0...92.4 V
- Accuracy : <0.2%
Output current DC : Output 1+2: 0...5 A Output 3: max. 4 A
- Load regulation 0-100% ΔUDC : <0.15%
- Ripple output 1+2 (1 : <9 mAPP / <3 mARMS
- Accuracy : <0.3%
Efficiency : 0.85
Output power : 2x 160 W + 1x 12 W
Cooling : Fanless, natural convection
Operation temperature : 0...50 °C
Storage temperature : -20...70 °C
Dimensions (WxHxD) : Enclosure: 282x82x243 mm Overall: 282x90x260 mm
Weight : 4 kg
(1) RMS value: measures at LF with BWL 300 kHz, PP value: measured at HF with BWL 20MHz
